GPS/GLONASS Galileosky 7x

Price: 222 USD

In stock

Code: 00-00011596

pcs.

Buy

Buy in 1 click

Request a sample

Description

Galileosky 7x combines advanced GPS/GLONASS monitoring technologies Easy Logic and CAN Scanner, as well as the Exigner Driver App for drivers. Moreover, the novelty allows you to work with two CAN-buses simultaneously, transfer data from sensors and devices not only through the support of RS 485, RS 232, 1-Wire protocols, but also via Bluetooth 5.0 interface. Galileosky 7x modifications are available with external and internal antennas.

Technical Specifications

Manufacturer	Galileosky
Navigation module	GPS/GLONASS
GPS/GLONASS antenna	Internal, external connection possible
GSM module	2G
GSM frequency bands	850/900/1800/1900 MHz
Number of SIM cards	2
SIM card type	Nano-SIM
Supply voltage, V	9 - 39
Built-in battery	600 mA
Battery type	Li-Ion
Interfaces	1-Wire / Bluetooth / CAN / RS-232 / RS-485
Discrete output	4
Universal input	6, analog-discrete and pulse-frequency
SD card slot	Yes
PC connection	USB
Code	00-00011596
Link	http://base.galileosky.com/articles/#!docs-publication/galileosky-7x-user-manual
Built-in memory	16 МБ (450000 точек)
2 way voice communication	Yes (when connecting external speaker and microphone/pTT)
Accelerometer	Yes
SMS setup	Yes
Supported CAN protocols	SAE J1979 / SAE J1939
Working temperature	-40°С - +85°С
Dimensions	102 х 68 х 24 mm
Weight	150 g
Case protection	IP54
